v60 Highlights

The Aptus PC software is compatible with all Intellian VSAT antennas and can also be used with its 3-Axis TVRO systems. The software is connected via the onboard network, allowing for use with an onboard PC through a one-click installation process. Intellian is a leading global technology and solutions provider for satellite communications and satellite tv, empowering connectivity for the maritime, government, military, energy, cruise and enterprise sectors.

Intellian i6PE is primary designed for receiving satellite signal at polar regions with its low elevation angle design. With an extra pointing angle, Intellian i6PE can track satellite down to 15 and up to 90 degrees elevation. Enjoy satellite broadcasts at sea Intellian i6PE is the most modern antenna system that enables you to. B3-914S Intellian i9 Satellite TV Antenna System ( US ) B3-910Q Intellian i9 Satellite TV Antenna System ( Europe ) Physical. Radome Height 121 cm / 47.5” Radome Diameter 113cm / 44.5” Antenna Dish Diameter 85 cm / 33.5” Weight 124 lbs ( 56.2 kg ) Environmental. Range -13˚F to +131˚F ( -25˚C to +55˚C ) Storage Temp.

Intellian’s proprietary global Ku-band PLL LNB

v60G variant features combined BUC Power and TX Signal to reduce system cabling

Dual VSAT Mediator integrates two VSAT antennas to combat onboard blockage zones

Open platform system architecture works with all leading Ku-band service providers

Remote Management using Aptus Web. Wi-Fi enabled ACU for local control using Aptus Mobile or PC

Gyro-Free Satellite Search Capability without input from a ships compass

Shorten installation time and reduce maintenance visits with automated diagnostics

3-Year Global Warranty backed by over 300 Intellian Service and Support centers around the world

Superior tracking performance

The v60 provides always-on, uncompromised performance with the highest quality and reliability, providing a continuous connection at sea. The v60 is the ultimate choice for mariners who are seeking a commercial grade broadband experience with a compact, robust and cost-effective solution.

Intellian Antenna Pc Controller Manual

Patented RF Technology

The v60 incorporates Intellian’s patented Global PLL LNBs supporting an unlimited number of LO frequencies, both cross-pol and co-pol feeds and offers BUC options from 4W to 16W. This is an ideal system for vessels that require a small mounting footprint, as well as simple installation, ease of operation and reliable remote maintenance accessibility.

The v60G supplies BUC power using the TX signal cable directly from the ACU, reducing the number of antenna cables to run, while maintaining superior signal linearity and avoiding common problems associated with signal stacking into one cable.

The v60 can be configured for SCPC, TDMA or hybrid broadband satellite networks. It is suitable for high-speed Internet, weather & chart updates, email, file and image transfer, video conference, VoIP, VPNs and database backup.

v60 Features

Intellian Antenna Pc Controller Download

Remote Access via Aptus Web

Intellian Antenna Pc Controller

Built-in web interface: Remote Upgrades, Automatic Diagnostics
Access all onboard Intellian antennas (including TVRO) through the onboard network

Global Operation, One Antenna
Standard equipped with Intellian’s patented Global PLL LNB, capable of receiving a full range of operating frequencies from any VSAT satellite around the globe
All Intellian VSAT antennas are Co-pol and X-pol compatible

Gyro-free Operation
No required input from ship’s heading device
Quick setup to reduce installation time. Automated Bow offset function in Aptus

Global Satellite Library
Preinstalled database of detailed satellite data with one-touch remote updating feature through Aptus
Customizable satellite library for a specific network

Auto Beam Switching (ABS)
Supports ABS via the OpenAMIP protocol from iDirect and Comtech’s ROSS Open Antenna Management (ROAM) protocol

Open Platform Compatibility
Fully compatible with all major service providers
Preconfigured modem settings provided in a simple drop down menu using Aptus

Optional Dual VSAT Mediator
Ensures uninterrupted broadband communications by seamlessly switching between two antennas
Communicates simultaneously with two Antenna Control Units (ACU). Ideal for redundant antenna environments

Global Support
Over 300 Intellian Service and Support centers around the world

3 Year Global Warranty
Industry leading 3-year parts and workmanship guarantee with a 2-year labor warranty for all antenna systems, ensuring peace of mind with your hardware investment
The new warranty policy (3 year parts and 2 year labor) is only valid for products purchased after 1st, January 2017

Anatel Approved
Approved for sale and operation in Brazil
